RAY EP

Transmitters

Fernbedienung RAY EP für industrielle Funksteuerungen

1/9

2/9

3/9

4/9

5/9

6/9

7/9

8/9

9/9

One-step push-button panel, ultra flexible

Compact single-click push-button panel with an innovative and versatile design. Lithium polymer battery that guarantees a battery life of over 25 hours. Automatic management of the radio transmission channel with AFA technology. Extensive customization of the command layout. Maximum safety level according to international standards thanks to the emergency stop button.

Download PDF sheet Request a quote

Optionals Receivers

Fields of application

Dust fighters

Sewer vacuum pumps

Dust fighters

Forklifters loaders

Recovery and tow vehicles

Concrete mixing plants

Tracked machines

Crushers and screeners

Harvesting machines

Trenching machines

Tunneling boring machines (TBM)

Forestry machinery

Yacht/boat mooring

Hoist winches

Cableways rope cranes

Others

Main features Certifications Main technical data Receivers

No limits of application!

IMET supports Manufacturers and System Integrators in customizing products according to the needs of their applications. Prototypes and pilot series are created. Once the specifications are defined, the customer plans the supplies. The technology and systems that IMET has invested in enable a large and diversified production capacity, ensuring product repeatability within timelines that meet the customer's needs.

Total configurability

The CNC drilling of the boxes and the multi-colored digital printing and cutting of the panels are realized internally. Along with a highly dynamic Technical Department, IMET can meet the most varied needs of manufacturers. The positioning of the components and the symbology are fully customizable.

Durability

With a focus on sustainability and long-term preservation, we use high-quality materials and components. IMET radio controls are designed to be used in the most extreme environments. To ensure durability, the products are tested internally with instruments that verify the protection level against liquid and dust penetration, aging through climatic tests, UV light, salt mist, and incandescent wire tests.

Repairable over time

Durable and repairable, this is the perspective on which IMET products are designed, all in function of a paradigm of environmental sustainability and cost reduction. There’s certainty of spare parts supplies over time, also for systems at the end of lifecycle, thanks to a structured and well-stocked warehouse.

Operating logic

IMET remote controls having physical outputs and depending on quantity, can be equipped with complex operating logic, developed according to manufacturer’s specifications. Our Technical Department, thanks to the know-how acquired in decades of experience in every sector, is capable of following you in every step of development.

Programming and diagnostic

Through a dedicated software (sold separately), you can set-up some parameters of the system. The programming tool acts as an interface to the PC. This device allows the reading of any diagnostic information about the system operation.

Harsh environments

The remote controls are designed and built to be used in the most demanding environments. In order to ensure the durability, the products are tested internally with instrumentation and systems that check infiltration, aging, salt spray, UV, fire; only to mention some.

Removable battery

Long-lasting rechargeable Li-Po or Ni-MH batteries allow continuous operation and a negligible memory effect. They are easily removable thanks to the quick coupling and are protected from any of liquid and powder penetration. Gold-plated contacts ensure stability and long service life.

TÜV nord certification

Product conforming to the machinery directive 2006/42/CE certified by TÜV NORD Notified Body nr. NB 2261

CE certification

UKCA (United Kingdom) certification

IC certification

IC (Canada) certification

FCC certification

FCC (USA) certification

MIC certification

MIC (Japan) certification

KCC certification

KCC (Korea) certification

EAC certification

ACMA certification

ACMA (Australia) certification

RAY EP

Dimensions (L.W.A.)

180 x 80 x 43 mm

Weight (battery included)

350 g max

Max number of ON/OFF commands

Max number of analog commands (optional)

Max number of single-axis joysticks

Max number of dual-axis joysticks

Range

100 m

Casing material

Charged Nylon UL94 HB

Battery

NiMh 1,2V - 4300 mAh

Autonomy at 20°C with charged battery in continuous service

≃ 25 hours

UMFS protection

STOP	PLe Cat.4
STOP WITHOUT MUSHROOM BUTTON	PLc Cat.1
JOYSTICK	PLd Cat.3
SELECTOR LEVER - BUTTON	PLc Cat.2

Operating frequency 1

I.S.M. Band 433.050-434.790 MHz 69 programmable channels in AFA mode or on fixed channel. Max power: 1 mW e.r.p

Operating frequency 2

I.S.M. 434.040-434.790 MHz 30 programmable channels in AFA mode or on fixed channel. Max power: 10 mW e.r.p

Operating frequency 3

2,4 GHz 38 ch

Operating frequency 4

I.S.M. Band 863.100-869.850 MHz Number of programmable channels: 32 AFA mode (Adaptive Frequency Agility) + LBT with automatic channel selection. Max power: 20 mW e.r.p

Operating frequency 5

Band 915.200-927.800 MHz Number of programmable channels: 64 Frequency Hopping mode. Max power: 20 mW e.r.p

Color graphic display (optionals)

Operating temperature

-25°C - +55°C

Degree of protection

IP 65

Empfänger für Fernbedienungen für industrielle Anwendungen

Receiver Receiver S DC Discover more

Receiver Receiver S AC Discover more

Receiver Receiver L DC Discover more

Receiver Receiver L AC Discover more

Receiver Receiver H DC Discover more

Receiver Receiver H AC Discover more

Receiver Receiving unit Explosion proof Discover more

Receiver Receiver M AC Discover more

Additional optionals

Multi receiving and/or multi transmitting optional

MTRS allows a transmitter to communicate simultaneously with multiple receivers, also with data-feedback, and to pass the exclusive control of a receiver to other transmitters through a secure Lock and Unlock procedure.
